Item No.

JT-922

Performance parameters

Working Frequency

902~928 MHz or 865~868MHz

Protocol

ISO18000-6C(EPC C1 GEN2)

Chip

Impinj  R2000

RF

0～30dBm(Adjustable)

Software & SDK

DEMO and C#, VC, Java

Communication port

RS232,TCP/IP  OR  RS232,WIFI

Reading range

3M(Depends on antenna gain, tag & environment)

Storage space

1M or 8M Flash save without power supply(Customized)

Real-time clock

Without power supply, real-time clock save and working(customized)

Frequency modulation

hopping or fixed frequency

RSSI

RSSI numerical test

Antenna gain

8dBi circular polarization

Working way

Buzzer & Red flashing

Power

12V/3A Adaptor

Physical Parameters:

Item size

Height:1500mm,Screen:1450x600x90mm,Base:600x400x50mm

Net weight

38kg(Single gate)

Shell material

Aluminum Alloy

Working temperature

-20℃~+65℃

Storage temperature

-45℃~+95℃
