Protocol

EPC Class1 Gen2; ISO18000-6C

Working Frequency

902-928MHz or 865-868MHz

Chip

NXP UCODE 8/Impinj M730/R6P

Chip memory

EPC 128bits/96bits

Read/write

Data storage

50 years

ABS

Surface color

light blue

Size

95mm *25mm* 5mm

Positioning hole size

The diameter of the positioning hole for product fixing is 3.6mm, and the center spacing of the positioning hole is 88mm

Working temp.

-25~ +80℃

Storage temp.

-30~ +80℃

Storage humidity

5%～95%

Install method

Screws, rivets, super glue (not standard), 3M300LSE double-sided adhesive (standard)

Weight

18g/pcs

Carton

Drop test

Passed 200 drop tests from 1 meter height

Alcohol test

95% alcohol test passed

Gasoline test

92 gasoline wipe through

High and low temperature alternating test

-30℃～+80℃ 7 times of high and low temperature alternating cycles, a total of 2 consecutive days passed the test

RoHS

Passed, the material is certified by SGS

IP

IP67

Fixed reader (on metal)

> 8 meters (using JT-928 fixed reader, if other readers, the reading distance may be different)

Handheld reader (on metal)

> 5.0 meters (the reading distance of JT-973 handheld reader in outdoor open space, if other handhelds are used, the reading distance may be different)

Polarization mode

Linear polarization

RF Performance Consistency Testing

100% tested and passed (tested by European Finnish Voyantic Tagformace tester)

Optional

Laser coding, surface LOGO screen printing, pre-writing, surface pattern processing, surface variable one-dimensional code or two-dimensional code processing
